3D Printing Resin Types
Prototyping and production is a whole lot faster and practical thanks to Nexa3D’s ever-expanding library of functional resin materials for 3D printing tailored to meet your every need, from general purpose prototyping to industry-specific manufacturing at scale.
Resin Materials
Use with NXE 400, NXE 200, NXD 200, and XiP
Thermoplastic Materials
Use with QLS 820
-
KeyGuide
Measurement Value Unit Test Method Flex Modulus 2400 MPa ASTM D790 Flex Strength 105 MPa ASTM D790 Biocompatibility Pass /ISO 10993-5 Biocompatibility Pass /ISO 10993-10 -
KeyModel Ultra
Measurement Value Unit Test Method Tensile Modulus >1700 MPa D638 Ultimate Tensile Strength >50 MPa D638 Tensile Elongation at Break 5 % D638 Flex Modulus >1940 MPa D790 Flex Strength >70 MPa D790 -
KeySplint Soft
Measurement Value Unit Test Method Tensile Elongation at Break >110 % D638 Flex Modulus 1100 MPa ASTM D790 Flex Strength 44 MPa ASTM D790 Flex Modulus 135 MPa ISO 20795-2 Flex Strength 2.6 MPa ISO 20795-2 Hardness (Shore D) 80 ASTM D2240 HDT @0.45 MPa 32 oC ASTM D648 Sorption <18 μg/mm3 ISO 20795-2 Solubility <4.8 μg/mm3 ISO 20795-2 Free Monomer Extraction Pass ISO 20795-2 Cytotoxicity Pass ISO 10993 Irritation Pass ISO 10993 Sensitization Pass ISO 10993 -
KeyTray
Measurement Value Unit Test Method Tensile Modulus/ASTM D638 2056 MPa ASTM D638 Ultimate Tensile Strength 62 MPa ASTM D638 Tensile Elongation at Break 26 % ASTM D638 Flex Modulus 1913 MPa ASTM D790 Flex Strength 85 MPa ASTM D790 Hardness (Shore D) 86 ASTM D2240 -
x45-Black
Measurement Value Unit Test Method Tensile Modulus >1.6 GPa ASTM D638 Ultimate Tensile Strength >52 MPa ASTM D638 Tensile Elongation at Break >12 % ASTM D638 Flex Modulus >2.1 GPa ASTM D790 Flex Strength >95 MPa ASTM D790 Hardness (shore D) 84 ASTM D2240 Notched Izod 20 J/m ASTM D256 Water Absorption 6 % ASTM D570 -
x45-Clear
Measurement Value Unit Test Method Tensile Modulus >1.6 GPa ASTM D638 Ultimate Tensile Strength >52 MPa ASTM D638 Tensile Elongation at Break >12 % ASTM D638 Flex Modulus >2.1 Gpa ASTM D790 Flex Strength >95 Mpa ASTM D790 Hardness (shore D) 85 ASTM D2240 Notched Izod 19 J/m ASTM D256 Water Absorption 6 % ASTM D570 -
x45-Natural
Measurement Value Unit Test Method Tensile Modulus >1.6 GPa ASTM D638 Ultimate Tensile Strength >52MPa MPa ASTM D638 Tensile Elongation at Break >12 % ASTM D638 Flex Modulus >2.1 GPa ASTM D790 Flex Strength >95 MPa ASTM D790 Hardness (shore D) 85 ASTM D2240 Notched Izod 20 J/m ASTM D256 Water Absorption 6 % ASTM D570 -
xABS3843
Automation Machinery, Robotics, Bracket, Levers and Arms for Manufacturing Stations, Parts and AssembliesTechnical Datasheet Safety DatasheetMeasurement Value Unit Test Method Tensile Modulus 1400 MPa ASTM D638 Ultimate Tensile Strength 32 MPa ASTM D638 Tensile Elongation at Break 50 % ASTM D638 Flex Modulus 1400 MPa ASTM D790 Flex Strength 30 MPa ASTM D790 Hardness (Shore D) 86 ASTM D2240 Notched Izod 54 J/m ASTM D256 HDT @0.45 MPa 56 oC ASTM D648 Water Absorption 2.35 % ASTM D570 -
xCE-Black
Automotive Parts, Automation, Robotics, Industrial, Functional Injection Molding ToolsTechnical Datasheet Safety DatasheetMeasurement Value Unit Test Method Tensile Modulus 2840 MPa ASTM D638 Ultimate Tensile Strength 69 MPa ASTM D638 Tensile Elongation at Break 8 % ASTM D638 Flex Modulus 3250 MPa ASTM D790 Flex Strength 135 MPa ASTM D790 Hardness (Shore D) 89 ASTM D2240 Notched Izod 20 J/m ASTM D256 HDT @0.45 MPa 120 oC ASTM D648 Water Absorption 0.4 % ASTM D570 -
xCE-White
Automotive Parts, Automation, Robotics, Industrial, Functional Injection Molding ToolsTechnical Datasheet Safety DatasheetMeasurement Value Unit Test Method Tensile Modulus 2840 MPa ASTM D638 Ultimate Tensile Strength 69 MPa ASTM D638 Tensile Elongation at Break 8 % ASTM D638 Flex Modulus 3250 MPa ASTM D790 Flex Strength 135 MPa ASTM D790 Hardness (Shore D) 89 ASTM D2240 Notched Izod 20 J/m ASTM D256 HDT @0.45 MPa 120 oC ASTM D648 Water Absorption 0.4 % ASTM D570 -
xCLEAN washing Solvent for All Resin-based 3D Printers
Measurement Value Unit Test Method Tensile modulus XY 2600 MPa ISO 527-1/-2 Tensile modulus Z 2600 MPa ISO 527-1/-2 Tensile stress at break XY 47 MPa ISO 527-1/-2 Tensile stress at break Z 30 MPa ISO 527-1/-2 Strain at break XY 4 % ISO 527-1/-2 Strain at break Z 1.2 % ISO 527-1/-2 -
xFLEX475-Black
Pipes and Manifolds, Handles and Grips, Seals and Gaskets, Sportswear and Footwear MidsolesTechnical Datasheet Safety DatasheetMeasurement Value Unit Test Method Tensile Modulus 3.7 MPa Ultimate Tensile Strength 2.5 MPa ASTM D638 Tensile Elongation at Break 150 % ASTM D638 Energy Return 47 % Internal Tear Strength 7.3 kN/m ASTM D624 Hardness (shore A) 44 A ASTM D2240 -
xFLEX475-White
Pipes and Manifolds, Handles and Grips, Seals and Gaskets, Sportswear and Footwear MidsolesTechnical Datasheet Safety DatasheetMeasurement Value Unit Test Method Tensile Modulus 4.6 MPa Ultimate Tensile Strength 3.8 MPa ASTM D638 Tensile Elongation at Break 159 % ASTM D638 Energy Return 39.13 % Internal Tear Strength 11.77 kN/m ASTM D624 Hardness (shore A) 55 A ASTM D2240 -
xGPP-Gray
Quick Design Verification Models, Display Models, Models where accuracy and resolution are criticalSafety DatasheetMeasurement Value Unit Test Method Ultimate Tensile Strength 30-60 MPa ASTM D638 Tensile Elongation at Break 4-5.5 % ASTM D638 Hardness (Shore D) 84 – 88 ASTM D2240 HDT @0.45 MPa 59 – 61 oC ASTM D648 Water Absorption 0.4 % ASTM D570 -
xGPP-Translucent
Performance Prototype, Functional End User Parts, Air Duct, Fluid Flow Models, Snapp FitSafety DatasheetMeasurement Value Unit Test Method Ultimate Tensile Strength 30-60 MPa ASTM D638 Tensile Elongation at Break 4-5.5 % ASTM D638 Hardness (Shore D) 84 – 88 ASTM D2240 HDT @0.45 MPa 59 – 61 oC ASTM D648 Water Absorption 0.4 % ASTM D570 -
xMODEL
Measurement Value Unit Test Method Tensile Modulus 2.5 Gpa ASTM D638 Ultimate Tensile Strength 54 Mpa ASTM D638 Tensile Elongation at Break 4 % ASTM D638 Flex Modulus 2.1 Gpa ASTM D790 Flex Strength 83 MPa ASTM D790 Hardness (Shore D) 73 ASTM D2240 -
xPA11
Measurement Value Unit Test Method Tensile Modulus 1500 MPa ISO 527 Tensile strength at yield 45-50 MPa ISO 527 Elongation at yield 18-24 % ISO 527 Tensile strength at break 45 % ISO 527 Elongation at break 45 % ISO 527 Flexural modules 1200 MPa ISO 178 (23°C) Shore D hardness 77 ISO 868 (23°C) Impact strength (Charpy – unnotched) No break ISO 179 1eU (23°C) -
xPA12
Measurement Value Unit Test Method Tensile modulus 247 ksi ASTM D638 Young’s strength 6962 psi ASTM D638 Elongation at break 24 % ASTM D638 Flexural modulus 217 ksi ASTM D790 Flexural strength 8412 psi ASTM D790 Shore D – hardness 75 – ASTM D2240 -
xPBT
Measurement Value Unit Test Method Tensile modulus XY 2600 MPa ISO 527-1/-2 Tensile modulus Z 2600 MPa ISO 527-1/-2 Tensile stress at break XY 47 MPa ISO 527-1/-2 Tensile stress at break Z 30 MPa ISO 527-1/-2 Strain at break XY 4 % ISO 527-1/-2 Strain at break Z 1.2 % ISO 527-1/-2 -
xPEEK147
Measurement Value Unit Test Method Tensile Modulus 3190 MPa ASTM D638 Ultimate Tensile Strength 75 MPa ASTM D638 Tensile Elongation at Break 3 % ASTM D638 Flex Modulus 3170 MPa ASTM D790 Flex Strength 130 MPa ASTM D790 Hardness (Shore D) 94 ASTM D2240 Notched Izod 15 J/m ASTM D256 HDT @0.45 MPa 238 oC ASTM D648 Water Absorption 0.25 % ASTM D570 -
xPP405-Black
Measurement Value Unit Test Method Tensile Modulus 1300 MPa ASTM D638 Ultimate Tensile Strength 35 MPa ASTM D638 Tensile Elongation at Break 100 % ASTM D638 Flex Modulus 1300 MPa ASTM D790 Flex Strength 45 MPa ASTM D790 Hardness (Shore D) 80 ASTM D2240 Notched Izod 62 J/m ASTM D256 HDT @0.45 MPa 53 oC ASTM D648 Water Absorption 1.00 % ASTM D570 -
xPP405-Clear
End Use Parts for Packaging, Bottling, Piping, Consumer and Industrial ApplicationsTechnical Datasheet Safety DatasheetMeasurement Value Unit Test Method Tensile Modulus 1300 MPa ASTM D638 Ultimate Tensile Strength 35 MPa ASTM D638 Tensile Elongation at Break 100 % ASTM D638 Flex Modulus 1300 MPa ASTM D790 Flex Strength 45 MPa ASTM D790 Hardness (Shore D) 79 ASTM D2240 Notched Izod 62 J/m ASTM D256 HDT @0.45 MPa 53 oC ASTM D648 Water Absorption 2.00 % ASTM D570 -
xPRO410
Quick Design Verification Models, Display Models, Models where accuracy and resolution are criticalTechnical Datasheet Safety DatasheetMeasurement Value Unit Test Method Tensile Modulus 2365 MPa D638 Ultimate Tensile Strength 41 MPa D638 Tensile Elongation at Break 5.5 % D638 Hardness (Shore D) 79 D2240 Notched Izod 25 J/m D256 HDT @0.45 MPa 61 oC D648 Water Absorption 0.46 % D570
Download Material Guide
Wondering what material is best for your application? Download our free material selection guide to learn more about material characteristics and applications.
